SPAL Automotive
SPAL Thermo Puller Fan - 10" - 12V - 1103 CFM - VA15-AP70/LL-39A
The VA15-AP70/LL-39A (EF9631) 12V 10" SPAL Puller Fan is a low profile unit with a straight blade design and boasts a combined airflow rating of 1103cfm / 1870m3/h.
Suitable for a range of auto and machinery applications, the VA15-AP70/LL-39A puller unit is triple-balanced for extended longevity and performance. Boasting an IP68-rated water and dust-proof motor of exceptional quality and a protective finger guard shroud, this SPAL fan is built to last and is supported by a 3-year manufacturer's warranty.
| EF9631 10" SPAL THERMO FAN DETAILS | |
|---|---|
| SPAL Fan Model # | VA15-AP70/LL-39A |
| US Part # | 30102057 |
| Voltage | 12V |
| Flow Type | Puller |
| Blade Diam. | 10 inch (255mm) |
| Blade Type | Straight Paddle |
| Shroud Type | Open Shroud |
| Unit Weight | 2.55kg |
| Amps | 10.5 |
| CFM | 1103 |
| M3/H | 1870 |
| Spec. Sheet |
View Specifications
|
| Warranty | View Warranty Info |
| Included | SPAL Fan w/Standard Connector See SPAL Accessories for Mounts etc. |
| EF9631 10" SPAL THERMO FAN DIMENSIONS | |
|---|---|
| A | 145mm / 5.71" |
| B | 303mm / 11.93" |
| C | 269.2mm / 10.59" |
| D | 286mm / 11.26" |
| E | 95.4mm / 3.76" |
 |
|
| ABOUT SPAL |
|---|
|
All SPAL Fans are individually balanced & tested to provide optimal performance and life. From the motor to the fan to the shroud, all components are completely designed, manufactured and tested in SPAL's state-of-the-art facility in Correggio, Italy. SPAL fans are sold without extra mounting hardware. See the SPAL Fan Accessories section for these items.
|
Designed to withstand the harshest environments, SPAL fans are unmatched in quality and reputation.
