The VA09-AP8/LL-54SĀ (EF3575) 12vĀ 11"Ā SPAL Pusher Fan is a Medium-Profile Thermo Fan featuring a Finger Guard Shroud and a Skew (curved) Blade Design which can push up to 832cfm / 1410m3/h.
The EF3575 11" Fan is individually balanced for long lifeĀ and features a fully sealed waterĀ & dust-proof motor of superior quality and backed with a 3-year manufacturers warranty.Ā
| VA09-AP8/LL-54SĀ FAN DETAILS | |
|---|---|
| SPAL Fan Model # | VA09-AP8/LL-54S |
| Voltage | 12V |
| Flow Type | Pusher |
| Blade Diam. | 11 inch (280mm) |
| Blade Type | Skew |
| Shroud Type | Finger Guard |
| Amps | 6.4 |
| CFM | 832 |
| M3/H | 1410 |
| Spec. Sheet |
View SpecificationsĀ
|
| Warranty | View Warranty Info |
| VA09-AP8/LL-54S FAN DIMENSIONS | |
|---|---|
| A | 294mm / 11.57" |
| B | 310mmĀ / 12.2" |
| C | 155mm / 6.1" |
| D | 268mmĀ / 10.55" |
| E | 65mm / 2.56" |
 |
|
Ā
Article:Ā What Do SPAL Model Numbers Mean?
Ā
All SPALĀ Fans are individually balanced & tested to provide optimal performance and life. From the motor to the fan to the shroud, all components are completely designed, manufactured and tested in SPAL's state-of-the-art facility in Correggio,Ā Italy.
